Triumph Speed Triple Handbook

101
Maintenance and Adjustment
The spring pre-load adjusters are located at
the top of each fork.
To change the spring pre-load, rotate the
adjuster clockwise to increase pre-load, or
anti-clockwise to decrease pre-load. Always
count the number of clockwise turns from
the fully anti-clockwise position and set both
forks to the same settings.
• For Speed Triple and
Speed Triple R the motorcycle is
delivered from the factory with
the spring pre-load set at
7 clockwise turns from the fully
anti-clockwise position.
Rebound Damping Adjustment
Speed Triple
1. Rebound damping adjuster
The rebound damping adjuster is located at
the top of each fork
To change the rebound damping force, rotate
the slotted adjuster clockwise to increase, or
anti-clockwise to decrease. Always count the
number of anti-clockwise turns from the fully
clockwise position and set both forks to the
same settings.
Note:
• The motorcycle is delivered from
the factory with the rebound set at
1.5 anti-clockwise turns from the
fully clockwise position.
1
cgfj_2

Triumph Speed Triple Specifications

General

Transmission	6-speed
Engine Type	Liquid-cooled, 12-valve, DOHC, in-line 3-cylinder
Front Suspension	Öhlins 43mm NIX30 upside down forks, adjustable compression, rebound and preload
Rear Suspension	Öhlins monoshock, adjustable compression, rebound and preload
Front Brakes	twin 320mm floating discs
Rear Brakes	Brembo single piston caliper, 220mm disc
Fuel Tank Capacity	15.5 litres
