119
Maintenance and Adjustment
Reconnect the battery, positive (red) lead first.
Refit the front panel and tighten the fixings to
3Nm.
Rear Light
Rear Light Replacement
The rear light unit is a sealed, maintenance
free LED unit.
Direction Indicator Lights
Bulb Replacement
1. I n d i c a t o r l e n s
2. Securing screw
The lens on each indicator light is held in
place by a securing screw located in the lens
of the light.
Release the screw and remove the lens to
gain access to the bulb for replacement.
Do not reconnect the battery until the
assembly process has been completed.
Premature battery reconnection could
result in ignition of the battery gases
causing risk of injury.
