Triumph Speed Triple Handbook

29
General Information
When the correct setting is shown press
button 'B' and the rpm 100 units start
flashing.
1. R P M 10 0 u n i t s
2. Button A
3. Button B
The setting can now be changed in
increments of 100 rpm, again up to the
maximum rpm limit.
Note:
• In this mode, when 900 is reached,
the next press of button 'A' will
reset the display to 000.
Each individual press of button 'A' will
increase the setting in increments of 100 rpm.
When the correct setting is shown, pressing
button 'B' will confirm the setting, SHIFt will
be visible in the display screen and all the
gear change lights will flash.
Press and release button 'A' until r
Eturn is
visible in the display screen then press
button 'B'. Trip 1 will be visible in the display
screen.
Setting Gear Change Lights to Off
To select the OFF mode, ensure OFF is visible
in the display screen. Press button 'B' and
SHIFt will be visible in the display screen.
Press and release button 'A' until r
Eturn is
visible in the display screen then press
button 'B'. Trip 1 will be visible in the display
screen.
1. Gear change lights
2. Display screen (OFF mode shown)
chdo_3
1
3
2
chdo_5
2
1

Triumph Speed Triple Specifications

General

Transmission	6-speed
Engine Type	Liquid-cooled, 12-valve, DOHC, in-line 3-cylinder
Front Suspension	Öhlins 43mm NIX30 upside down forks, adjustable compression, rebound and preload
Rear Suspension	Öhlins monoshock, adjustable compression, rebound and preload
Front Brakes	twin 320mm floating discs
Rear Brakes	Brembo single piston caliper, 220mm disc
Fuel Tank Capacity	15.5 litres
