Triumph Speed Triple Handbook

120
Maintenance and Adjustment
Licence Plate Light
Bulb Replacement
Remove the front panel from the fuel tank.
Disconnect the battery, negative (black) lead
first.
Remove the fixings for both rear indicators.
1. Fixing, left hand side shown
2. Licence plate bracket
Carefully raise the licence plate bracket to
gain access to the locknut.
Counter-hold the locknut to prevent it from
turning and remove the licence plate light
fixing. Collect the locknut.
Detach the light from the bracket. It is not
necessary to disconnect the electrical
connectors.
Carefully remove the bulb holder from the
back of the light unit. Remove the bulb.
1. Licence plate light
2. Bulb holder
Installation is the reverse of the removal
procedure, noting the following:
Tighten the lamp fixing to 2Nm.
Tighten the rear indicator fixings to 3Nm.
Reconnect the battery, positive (red) lead first.
Refit the front panel and tighten the side
fixings to 3Nm.
Caution
Do not pull the licence plate bracket more
than is necessary to access the light's inside
fixing nut. Damage to the bracket will
result from pulling it too far.
1
2
Caution
To avoid cable damage, do not pull the
bulb holder using the cables. Pull only on
the bulb holder.
1
2

Triumph Speed Triple Specifications

General

Transmission	6-speed
Engine Type	Liquid-cooled, 12-valve, DOHC, in-line 3-cylinder
Front Suspension	Öhlins 43mm NIX30 upside down forks, adjustable compression, rebound and preload
Rear Suspension	Öhlins monoshock, adjustable compression, rebound and preload
Front Brakes	twin 320mm floating discs
Rear Brakes	Brembo single piston caliper, 220mm disc
Fuel Tank Capacity	15.5 litres
