Triumph Speed Triple Handbook

Specifications
127
SPECIFICATIONS
Dimensions
Overall Length . . . . . . . . . . . . . . . . . . . . . . . . 2,100 mm (82.6 in)
Overall Width . . . . . . . . . . . . . . . . . . . . . . . . . 795 mm (31.3 in)
Overall Height. . . . . . . . . . . . . . . . . . . . . . . . . 1,110 mm (43.7 in)
Wheelbase. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1,435 mm (56.5 in)
Seat Height . . . . . . . . . . . . . . . . . . . . . . . . . . . 825 mm (32.5 in)
Weights
Wet Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4 k
g
Maximum Payload
. . . . . . . . . . . . . . . . . . . . . 195 kg
Engine
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . In-line 3 cyl.
Displacement. . . . . . . . . . . . . . . . . . . . . . . . . . 1050 cc
Bore x Stroke . . . . . . . . . . . . . . . . . . . . . . . . . 79 x 71.4 mm
Compression Ratio . . . . . . . . . . . . . . . . . . . . . 12.0:1
Cylinder Numbering. . . . . . . . . . . . . . . . . . . . Left to Right
Cylinder Sequence Number. . . . . . . . . . . . . . 1 at left
Firing Order . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2-3
Starting System . . . . . . . . . . . . . . . . . . . . . . . . Electric Starter
Performance
Maximum Power (95/1/EC) . . . . . . . . . . . . . . 135 PS (133 bhp) at 9,400 rpm
Maximum Torque . . . . . . . . . . . . . . . . . . . . . . 111 Nm (82 ft.lbf) at 7,750 rpm

Triumph Speed Triple Specifications

General

Transmission	6-speed
Engine Type	Liquid-cooled, 12-valve, DOHC, in-line 3-cylinder
Front Suspension	Öhlins 43mm NIX30 upside down forks, adjustable compression, rebound and preload
Rear Suspension	Öhlins monoshock, adjustable compression, rebound and preload
Front Brakes	twin 320mm floating discs
Rear Brakes	Brembo single piston caliper, 220mm disc
Fuel Tank Capacity	15.5 litres
