Triumph Speed Triple Handbook

32
General Information
Data Retrieval Mode
1. Lap number
2. Stop watch icon
3. Lap timer
4. Button A
5. Button B
The data retrieval mode can be accessed in
one of two ways:
• With the ignition in the ON position,
from the lap timer display, press
button 'B'.
• From the Data Recording Mode,
with the engine running and the
motorcycle stationary, press the
starter button for 2 seconds. This will
return the display to the 'Lap'
display. From here press button 'B'.
Note:
• The data retrieval mode cannot be
accessed whilst the motorcycle is
in motion.
When the data retrieval mode is accessed, the
lap time for the first lap will be displayed. The
lap number will be displayed in the
speedometer display position.
1. Lap number
2. Stop watch icon
3. Lap timer
4. Button A
5. Button B
Press and release button 'A' until the desired
lap (up to a maximum of 50 laps) is
displayed.
Press and release button 'B' to scroll through
the data available in the following order:
• Average Speed (per lap or total of all
laps)
• Maximum Speed (per lap or
maximum speed achieved)
1
cfiv_12
3
2
5
4
1
cfiv_12
3
2
5
4

Triumph Speed Triple Specifications

General

Transmission	6-speed
Engine Type	Liquid-cooled, 12-valve, DOHC, in-line 3-cylinder
Front Suspension	Öhlins 43mm NIX30 upside down forks, adjustable compression, rebound and preload
Rear Suspension	Öhlins monoshock, adjustable compression, rebound and preload
Front Brakes	twin 320mm floating discs
Rear Brakes	Brembo single piston caliper, 220mm disc
Fuel Tank Capacity	15.5 litres
