Triumph Speed Triple Handbook

28
General Information
Note:
• The motorcycle is delivered from
the factory with the gear change
light set to the 6 LED mode at
3,500 rpm.
1. Gear change lights
2. Display screen (3 mode shown)
3. Button A
4. Button B
When the gear change light mode has been
selected, the tachometer needle will move
round to the last set position. The rpm will be
shown in the display screen with the
1,000 units flashing.
1. RPM 1,000 units
2. Button A
3. Button B
Changing the Set Speed
To change the setting in increments of
1,000 rpm, press button 'A'. Each individual
press of button 'A' will then increase the
setting in increments of 1,000 rpm, up to the
maximum rpm limit. When the maximum
rpm limit is reached, the setting will return to
3,500 rpm.
Note:
• If the rpm 1,000 units is set to the
maximum rpm limit, SHIFt will be
shown.
chdo_2
2
4
1
3
chdo_3
1
3
2

Triumph Speed Triple Specifications

General

Transmission	6-speed
Engine Type	Liquid-cooled, 12-valve, DOHC, in-line 3-cylinder
Front Suspension	Öhlins 43mm NIX30 upside down forks, adjustable compression, rebound and preload
Rear Suspension	Öhlins monoshock, adjustable compression, rebound and preload
Front Brakes	twin 320mm floating discs
Rear Brakes	Brembo single piston caliper, 220mm disc
Fuel Tank Capacity	15.5 litres
