Moving direction
⊙
Turning:
Finish
A: Border
Start
(9)
(13)
(17)
(1)
(2)
(3)
(4)
(5)
(6)
(15)
(11)
(7)
(10) (14) (18)
(16) (12)
A
(8)
Backword
995E001A
<Effective plowing pattern>
(1) Sequential returning plowing
pattern
This pattern can be useful in a
well-planned eld in a good con-
dition.
The border shown in the gure is
the effective plowing width of the
rotavator and should be set a lit-
tle narrower than three times of
one plowing width.
The starting point is the ending
point.
Plow in a sequential pattern from
(1) to (6) and in a circular pattern
from (7) to (18).
When driving forward to plow,
have the bank on the right side.
Be careful not to press already-
plowed soil with the wheels.
•
•
•
•
•
•
