TOP LINK ADJUSTMENT
(1) The angle of an implement can
be adjusted by extending or re-
tracting the top link.
(2) After adjustment, x the adjust-
ing handle so that the link does
not become loose.
(3) The mounting location of the top
link is different by the type of
an implement. The 1st and 2nd
holes from the top are generally
used.
►
Top link xing bar
and adjusting handle
Adjusting handle
C
D
J10O337A
J10O339A
J10O338A
Adjusting link
Lift rod
adjusting
handle
Lower link
connecting
hole
LIFT ROD ADJUSTMENT (LEFT/
RIGHT)
Turn the handle clockwise to extend
the rod and turn it counterclockwise
to retract the rod.
Adjust the length of the lift rod to
keep the implement in balance.
(1) To adjust the height, lift the ad-
justing handle. After adjustment,
lower the handle and x it.
(2) Adjust the length according to
the type of an implement.
► LOWER LINK CONNECTING
HOLE
C: for rotary tiller and other types of
implements
D: for rotary tiller
ADJUSTING LINK
The adjusting link can be adjusted
to relieve vibration and shock.
►
►
