TYM T954 User Manual

2 - 2
DESCRIPTION OF OPERATION SYSTEM
(11) PTO Shift lever
This lever is used to select the
PTO speed.
Refer to the page B-30 as its op-
eration is coupled with the PTO
(AUTO) switch.
2) How to disconnect coupler
① Lower the implement on the
ground to release pressure in
the hydraulic hose.
② Stop the engine and operate the
remote hydraulic lever for 2 to
3 times to remove any residual
pressure in the hose.
③ Disconnect the male coupler on
the implement side while pull-
ing the external ring of the cou-
pler on the tractor side backward
slightly.
④ Wipe oil and dust from the cou
-
pler and plug the dust cover.
J10O327A
PTO shift lever
750 rpm - Neutral - 1000 rpm - Neutral - 540 rpm (SP)
1000rpm - Neutral - 540rpm (SC)
< PTO speed selection >
① Stop the PTO.
② With the PTO switch set in the
OFF position, place the PTO le-
ver into the desired speed po-
sition. (540 RPM, 750 RPM or
1000 RPM)
< Remote hydraulic valve coupler >
1) How to connect coupler
① Clean the couplers on the tractor
and implement thoroughly.
② Remove the dust cover from the
tractor side. Then, fit the male
coupler on the implement side
while moving its external ring
backward slightly.
③ Pull the male coupler on the im
-
plement side backward slightly
to check its rm engagement.
J10O326A
123
Drain port
To prevent a burn and skin dam-
age, make sure to stop the en-
gine before connecting or discon-
necting the coupler.
Do not use your hands to check
for oil leakage.
•
•
WARNING
