5 - 
5
MAINTENANCE
Lamp lens
993F033A
REPLACING LAMP BULB
If a lamp does not come on by oper
-
ating the corresponding switch:
①
Check the corresponding fuse.
②
If the fuse is intact, remove the
bulb socket from the lamp.
③
Remove the bulb from the sock
-
et and check for blown lament.
④
If the lament is blown, replace
the bulb with a new bulb with the
same capacity.
►
RE PLACIN G TUR N SI G NAL
LAMP/POSITION LAMP
►
①
Remove the lamp lens using a
at-bladed screwdriver.
Bulb Specications
Handlamp 12V55W / 55W
Trun signal lamp (Front) 12V 21W
Turn signal lamp (Rear) 12V 21W
Position lamp (Front) 12V 8W
Stop/Position lamp 12V 21W / 5W
Backup lamp 12V 21W
Interior lamp 12V 10W
Work lamp H3 12V 35W
Position lamp (12 V 8 W)
993F034A
②
Remove the bulb by pressing it
and turning it counterclockwise.
Fit a new bulb by pressing it
turning it clockwise.
