(6) Main shift lever
The lever can be shifted among 4
speed positions. There are two but-
tons next to the lever for the SP
model.
(4) Throttle (Accelerator) pedal
It has the same function to the
throttle lever to control the en-
gine speed.
Depressing - The engine speed
is increased.
Releasing - The engine idles.
•
•
J10O319A
(5) Parking brake lever
Pull the parking brake lever up-
ward to apply the parking brake.
To release the parking brake,
press the button at the tip of the
lever.
J10O320A
Throttle
pedal
Parking
brake lever
The tractor does not move with
buzzer sound when operating the
shuttle shift lever with the park-
ing brake applied. In this case, re-
lease the parking brake with the
shuttle shift lever in the neutral po-
sition.
•
CAUTION
Make sure to park the tractor, stop
the engine and apply the parking
brake. Also, chock the wheels if
parking on a steep slope.
•
NOTE
J10O321A
Main shift
lever
①
②
