TYM T954 User Manual

9- 
9
APPENDIX
1-2. MAJOR SPECIFICATIONS (SC MODEL)
Type T954 T1054
Dimensions
Overall length (mm)
4,500 4,500
Overall width (mm)
2,470 2,470
Overall height (mm)
2,740 2,740
Ground clearance (mm)
465 465
Weight (kgf)
3,941 3,941
Engine
Manufacturer DOOSAN INFRACORE DOOSAN INFRACORE
Model number DL03-LEA05 DL03-LEA04
Total displacement (cc)
3,409 3,409
Power/rotation speed (Kw/rpm)
70.9 / 2,300 78.3 / 2,300
Operating fuel Diesel fuel Diesel fuel
Fuel tank capacity (ℓ)
110 110
Tires Rear wheel
13.6 - 24 13.6 - 24
16.9 - 34 18.4 - 34
Driving sys-
tem
Clutch (Damper)
Dry Dry
Braking Hydraulic Hydraulic
Transmission type Power shuttle Power shuttle
Gears F12/ R12 F12/ R12
Driving speed
(km/h)
Forward 1.2 - 30.2 1.3 - 31.2
Reverse 1.2 - 30.1 1.3 - 31.1
PTO Revolution (rpm)
540 / 1000
Implement Control type
position/draft
Draft system
Swing drawbar
