12.7 Installation → Mounting
Here the mounting of the robot arm can be specified. This serves two purposes:
1. Making the robot arm look right on the screen.
2. Telling the controller about the direction of gravity.
The controller uses an advanced dynamics model to give the robot arm smooth and
precise motions, and to make the robot arm hold itself when in Freedrive mode. For
this reason, it is very important that the mounting of the robot arm be set correctly.
WARNING:
Failure to set robot arm’s mounting correctly might result in frequent
protective stops, and/or a possibility that the robot arm will move
when the freedrive button is pressed.
The default is that the robot arm is mounted on a flat table or floor, in which case no
change is needed on this screen. However, if the robot arm is ceiling mounted, wall
mounted or mounted at an angle, this needs to be adjusted using the push-buttons.
The buttons on the right side of the screen are for setting the angle of the robot arm’s
mounting. The three top right side buttons set the angle to ceiling (180
◦
), wall (90
◦
),
floor (0
◦
). The Tilt buttons can be used to set an arbitrary angle. The buttons on the
lower part of the screen are used to rotate the mounting of the robot arm to match the
actual mounting.
WARNING:
Make sure to use the correct installation settings. Save and load the
installation files along with the program.
Version 3.1 (rev. 17782)
Copyright © 2009-2015 by Universal Robots A/S. All rights reserved.
II-27 CB3
