Fuel Tank
There are two alternative methods for calibrating the
level sensor in the fuel tank.
Multipoint provides more precise results while Full Fuel
Tank Calibration is an approximate method.
Multipoint calibration is a prerequisite if the trip
computer is to show fully accurate information.
Multipoint
In order for multi-point calibration to be carried out, the
fuel tank must not be filled to more than 20% of its total
capacity.
1 Turn to Fuel Tank in the settings menu and press
to access the calibration menu.
2
Turn to Multi-Point Calibration and press
.
3 Calibration is carried out in 5 steps.
Fill the tank with the quantity shown in the display,
POS).
Wait 10 seconds.
Press to confirm that the tank has been filled to
the indicated level.
4 Fill the tank with the quantity shown in the display,
POS 2.
Wait 10 seconds.
Press
to confirm that the tank has been filled to
the indicated level.
5 Repeat the procedure for POS 3 , POS 4 and POS
5. Confirm by pressing the wheel at each position.
.
Full Fuel Tank Calibration
For this method the tank must be full and the fuel level
sensor will be calibrated in one step. Thus, the fuel
level value will be approximate, and therefore all trip
data based on remaining fuel must be seen as
approximate values.
1
Turn to Fuel Tank and press to reach the
submenu.
2
Select Full Fuel Tank Calibration and press
.
3 Fill the fuel tank. Confirm that the fuel tank is full by
pressing
.
IMPORTANT:
An authorized Volvo Penta workshop is to carry out
Settings for Fuel Tank Volume, Empty Tank Calibration
and Fuel Alarm Level.
Multi-Point Calibration
Full Fuel Tank Calibration
Calibration and Settings
47712786 11-2022 © AB VOLVO PENTA 145
