Speed Factor
The speed factor must be set while the boat is under
way. Compare the displayed boat speed value with
GPS data (or another boat) and adjust the speed factor
until the values agree.
The setting just needs to be done on one display for it
to be shown at all stations and on all displays
1 Go from the settings menu to Speed Factor and
press
to reach adjustment.
2
Use to set the value
Press to confirm the setting.
Key Management
Adding or removing a key to or from the system can be
done in either the Battery Control Panel or the 2.5", 4"
and 7" displays. A system can have up to four keys,
which are numbered from 1-4.
Adding a key
1 Navigate to the menu Settings > Key Management.
2 When the text Show e-Key For Authorization is
shown, hold a key that is already registered in front
of the key panel. The system will check that the key
ID corresponds to a key registered in the system.
3 Select Add a key.
4 When the text Show e-Key To Add is displayed,
hold the new key in front of the panel. The system
will store the key ID.
5 The addition of the key is confirmed on the display.
Removing a key
1 Go to Settings > Key Management.
2 When the text Show e-Key For Authorization is
displayed hold a registered key in front of the key
panel. The system will check that the key ID
corresponds to a key registered in the system.
3 Select Remove key.
4 Select which of the keys 1–4 is to be removed.
Because the system must contain at least one key,
the key used for approval cannot be removed.
5 The removal of a key is confirmed on the display.
Speed Factor
P0016364
Key Management
Settings
Show e-Key
for Authorization
Add Key
Delete Key
Check Key
Show e-Key to Add
Key Management
Settings
Show e-Key
for Authorization
P0016500
Check Key
Delete Key
Add Key
e-Key 1
e-Key 2
e-Key 3
e-Key 4
Calibration and Settings
146 47712786 11-2022 © AB VOLVO PENTA
