1-8 BA DT08 SL EN – Edition 1.0 * * dt08b110.fm
Introduction
1.9 Type labels and component numbers
Serial number
The serial number is located on the type label.
The type label is located at the rear right of the control stand.
Type label information
Machine designation: COMPACT DUMPER
Model: ---------------
Model year: ---------------
CEE no.: ---------------
Output: ---------------
Serial no.: ---------------
Max. payload: ---------------
GWR: ---------------
Operating weight: ---------------
Front GAWR: ---------------
Transport weight: ---------------
Rear GAWR: ---------------
Version: ---------------
Other information – see chapter 6 Specifications on page 6-33
Engine number
The type label (arrow) is located next to the oil check plug.
The type label (arrow) is located below the tank (engine).
Fig. 3: Position of the type label
COMPACT DUMPER
Fig. 4: Engine number (petrol engine)
Fig. 5: Diesel engine number
