Wacker Neuson DT08-D User Manual

BA DT08 SL EN – Edition 1.0 * dt08b610.fm 6-37
Specifications
6.11 Dimensions model DT08-D with high-tip skip (option)
2570
1426
757
964
1134
274 753 518
3871545
8
2
°
1
3
°
234
180
790
764
1646
1240
1898
112
442
Fig. 90: Machine dimensions (model DT08-D with high-tip skip)
Main data
Model DT08-D
Payload
500 kg
Dead weight incl. skip and loader unit
625 kg
Length
1545 mm
Width
790 mm
Height
1240 mm
Foothold projection
387 mm
Track width
180 mm
Ground contact length of tracks
753 mm
Front skip projection
274 mm
Skip load height (front edge)
964 mm
Skip length
1134 mm
Skip width
764 mm
Skip depth
442 mm
