Wacker Neuson DT08-D User Manual

6-38 BA DT08 SL EN – Edition 1.0 * * dt08b610.fm
Specifications
6.12 Dimensions model DT08-P with skip
700
830
180
790
45
750
1845
386
1320
7
2
°
1
4
°
180
257
388
2520
515753
392
1660
420
1180
1313
Fig. 91: Machine dimensions (model DT08-P with skip)
Main data
Model DT08-P
Payload
500 kg
Dead weight incl. skip and loader unit
515 kg
Length
1660 mm
Width
790 mm
Height
1313 mm
Foothold projection
388 mm
Track width
180 mm
Ground contact length of tracks
753 mm
Front skip projection
392 mm
Skip load height (front edge)
750 mm
Skip length
1320 mm
Skip width
700 mm
Skip depth
386 mm
Scraping depth
45 mm
