3-24 BA DT08 SL EN – Edition 1.0 * * dt08b340.fm
Operation
Loading loose material
Do not carry out any steering movements once the bucket has penetrated the
material.
Lower the loader unit only when the machine is at a standstill and if there is
enough room to the front.
The loader unit is not designed for loading compacted material (hard to
penetrate), severe loader unit damage can occur.
☞ Only load loose material
☞ Lower the loader unit to the ground A
☞ Push control lever 1 forwards B
Do not carry out any steering movements once the bucket has penetrated the
material.
Load the machine only on firm and level ground!
☞ Drive forwards into the material A
If the engine speed decreases due to too much material:
☞ Raise the loader unit a little
☞ Pull control lever 1 backwards D
If the loader unit cannot be raised in the material
• Reduce the load on the loader unit by reversing
Ending loading
☞ Set the loader unit to position C
☞ Pull control lever 1 backwards D
Fig. 57: Horizontal lowering of the loader unit
A
1
B
Fig. 58: Driving into the material
A
1
D
Fig. 59: Tilt in the loader unit
C
1
D
