Wacker Neuson DT08-D User Manual

BA DT08 SL EN – Edition 1.0 * dt08b610.fm 6-39
Specifications
6.13 Dimensions model DT08-P with high-tip skip (option)
1426
2570
757
965
1134
8
2
°
274 753 515
3881540
764
180
790
257
1
4
°
1646
1180
1898
112
442
Fig. 92: Machine dimensions (model DT08-P with high-tip skip)
Main data
Model DT08-P
Payload
500 kg
Dead weight incl. skip and loader unit
580 kg
Length
1540 mm
Width
790 mm
Height
1180 mm
Foothold projection
388 mm
Track width
180 mm
Ground contact length of tracks
753 mm
Front skip projection
274 mm
Skip load height (front edge)
965 mm
Skip length
1134 mm
Skip width
764 mm
Skip depth
442 mm
Scraping depth
500 kg
