Accessories E 2200, E 3000ES
76 wc_tx001668gb.fm
5.7 Mounting the Auxiliary Pump Panel
Requirments  Machine shut down
 Power disconnected
 Auxiliary Pump Panel
Background The Wacker Neuson Auxiliary Pump Panel (APP) is an electrical device that
communicates with the main machine’s systems to provide protection for any
additional Pump Packs that are connected to the machine. If the machine
experiences a low level fault condition, the APP will cut off power to the external
components. This power cut-off protects the pumps from damage.
Guidelines Follow the guidelines below when mounting the APP. Refer to the diagram below.
 Install the APP inside the machine, near the main control panel (a).
 Install APP using included hardware (b).
