E 2200, E 3000ES Burner Setup
wc_tx001669gb.fm 89
6.5 Setting the Fuel Pressure
Requirements
Pressure gauge
See Factory Settings chart in topic Burner Setup for fuel pressure reading
Procedure
Follow the procedure below to check and adjust the fuel pressure.
1. Shut down the machine.
2. Remove the bleeder valve (a) from the fuel pump.
3. Insert the gauge in place of the bleeder valve.
4. If your machine has a generator, start it.
5. Move the Burner ON-OFF switch to the ON position. The burner will go through
a pre-purge cycle. Monitor and make adjustments during the pre-purge cycle.
6. Turn the adjusting screw (b) clockwise to increase fuel pressure,
counterclockwise to decrease fuel pressure.
Result
The fuel pressure has now been adjusted.
