5-16 BA 1404 en – Edition 2.7 * * 1404b520.fm
Maintenance
5.7 Replacing the cabin air filter
The filter elements will be damaged if they are washed or brushed out!
☞ Never reuse damaged filter elements.
☞ Ensure cleanliness when replacing the filter elements!
Clean the filter elements only with compressed air, bearing in mind the
following:
☞ Wear safety glasses and protective clothing
☞ Carefully clean the filter with compressed air
☞ Do not aim the compressed air at the skin or at other people
☞ Do not use compressed air for cleaning your clothing
The machine is equipped with a cabin filter located under the seat.
Clean the cabin filter every 500 operating hours, and replace it every 1000 operating hours.
☞ Stop the engine.
☞ Remove the key and carry it with you.
☞ Raise the control lever base.
☞ Remove screws A and the cover.
☞ Remove the filter and clean or replace it.
☞ Install the filter.
☞ Install screws A and the cover.
Abb. 198: Cabin air filter cover
A
