BA 1404 en – Edition 2.7 * 1404b610.fm 6-1
Technical data
6 Technical data
6.1 Chassis
Sturdy steel sheet chassis, rubber-mounted engine
6.2 Engine
Engine
1404/ET16
Product
Yanmar diesel engine
Type
3TNV76-SNS2
Design
Water-cooled 4 stroke diesel engine
Number of cylinders
3
Displacement
1116 cm³ (68 cu. in.)
Nominal bore and stroke
76 x 82 mm (2.9 x 3.2 in)
Power
13.2 kW at 2200 rpm
(17.7 hp at 2200 rpm)
Max. torque
65.8 Nm at 1600 rpm
(48.5 ft/lbs at 2200 rpm)
Max. engine speed without load
2375 +/− 25 rpm
Idling speed
1300 +/- 50 min
-1
(1,300 +/- 50 rpm)
fuel injection system
Indirect injection
Starting aid
Glow plug (preheating time 4 seconds)
Exhaust values according to
EPA – Tier IV final (up to 2012)
