Xilinx VC707 User Manual

VC707 Evaluation Board www.xilinx.com 81
UG885 (v1.4) May 12, 2014
Default Jumper Settings
J43 XADC VCC Select Header 2–3
J44 USB Mini-B Connector J2 GND jumper None
J45 USB SMBC U8 VBUS 1–2
J49 PCIe Bus Width Select Header 1-2
J50 TI Controller U64 Addr 54 Reset jumper None
J51 FMC_VADJ_ON_B jumper 1–2
J52 FPGA U1 INIT_B-to-PROG_B jumper None
J53 XADC VCC5V0-to-XADC_VCC5V0 jumper 1–2
J54 XADC REF3012 U35 V
IN
Select 1–2
Tab le A- 3: Default Jumper Settings (Cont’d)
Jumper Function
Default Jumper
Position
