Xilinx Virtex-5 RocketIO GTP User Manual

160 www.xilinx.com Virtex-5 RocketIO GTP Transceiver User Guide
UG196 (v1.3) May 25, 2007
Chapter 7: GTP Receiver (RX)
R
Figure 7-19 shows a waveform with a few error bytes arriving on RXDATA and the
RXNOTINTABLE and RXDISPERR ports indicating the error.
Figure 7-19: RX Data with 8B/10B Errors
RXUSRCLK2
RXDATA
RXDISPERR
RXNOTINTABLE
Good
Data
Good
Data
Both
Errors
Out of
Ta ble
Disp
Error
UG196_c7_19_092606
