Virtex-5 RocketIO GTP Transceiver User Guide www.xilinx.com 279
UG196 (v1.3) May 25, 2007
R
Appendix D
DRP Address Map of the GTP_DUAL
Tile
All attributes are stored as binary values in the DRP table. Some attributes use special
mappings from their UCF/HDL values to their binary values. The mappings for these
values are shown in Table D-1.
For attributes not listed in Table D-1, use the following rules to determine the binary
mapping:
• Attributes with TRUE/FALSE values use “1” to represent TRUE and “0” to represent
FALSE.
• Convert integer values to binary.
Tab le D - 1 : Special Attribute Mappings
Attribute UCF/HDL Attribute Value DRP Binary Value
CHAN_BOND_MODE
OFF 00
MASTER 01
SLAVE 10
CLK25_DIVIDER
1 000
2 001
3 010
4 011
5 100
6 101
10 110
12 111
