Chapter 3
Board Component Descriptions
Overview
This chapter provides a detailed functional description of the board’s components and
features. Ta b le 2 -1, page 13 identifies the components, references the respective schematic
page numbers, and links to the corresponding detailed functional description in this
chapter. Component locations are shown in Figure 2-1, page 12.
Component Descriptions
Zynq UltraScale+ XCZU28DR RFSoC
[Figure 2-1, callout 1]
The ZCU111 board is populated with the Zynq UltraScale+ XCZU28DR-2FFVG1517 RFSoC,
which combines a powerful processing system (PS) and programmable logic (PL) in the
same device. The PS in a Zynq UltraScale+ RFSoC features the Arm
®
flagship Cortex
®
-A53
64-bit quad-core processor and Cortex-R5 dual-core real-time processor.
For additional information on the Zynq UltraScale+ XCZU28DR-2FFVG1517 RFSoC, see the
Zynq UltraScale+ RFSoC Data Sheet (DS926) [Ref 2]. See the Zynq UltraScale+ Device
Technical Reference Manual (UG1085) [Ref 3] for more information about Zynq UltraScale+
RFSoC configuration options.
