ZCU111 Board User Guide 69
UG1271 (v1.1) August 6, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
Power and Status LEDs
[Figure 2-1, area of callout 22]
Tab l e 3- 2 5 defines the power and status LEDs. For user-controlled GPIO LED details, see
User I/O, page 65.
Table 3-25: Power and Status LEDs
Ref. Des. Schematic Net Name LED Color Description
DS1 PS_INIT_B Green/ Red
Green: FPGA initialization was successful.
Red: FPGA initialization is in progress.
DS2 PS_DONE Green RFSoC U1 bit file download is complete.
DS3 PS_RESET_B Red
POR U6 asserts RESET_B low when any of
the monitored voltages (IN_) falls below its
respective threshold, any EN_ goes low, or
MR is asserted.
DS4 PS_ERR_OUT Red
PS error out is asserted for accidental loss
of power, an error in the PMU that holds
the CSU in reset, or an exception in the
PMU.
DS5 PS_ERR_STATUS Red
PS er r or status indicates a secure lockdown
state. Alternatively, it can be used by the
PMU firmware to indicate system status.
DS6 PS_VCC3V3_PG Green DisplayPort 3.3V power on
DS7 USB3 MIC2544 U13 FLG Green PS USB 3.0 ULPI VBUS power error
DS27 ENET_LED_1 Green EHPY U37 1000BASE-T link is established.
DS47 MSP430_LED0 Green MSP430 U41 GPIO LED
DS46 MSP430_LED1 Green MSP430 U41 GPIO LED
DS11 GPIO_LED_7 Green USER GPIO LED
DS12 GPIO_LED_6 Green USER GPIO LED
DS13 GPIO_LED_5 Green USER GPIO LED
DS14 GPIO_LED_4 Green USER GPIO LED
DS15 GPIO_LED_3 Green USER GPIO LED
DS16 GPIO_LED_2 Green USER GPIO LED
DS17 GPIO_LED_1 Green USER GPIO LED
DS18 GPIO_LED_0 Green USER GPIO LED
DS19 VCC12_SW Green 12VDC power on
DS20 VCCINT_PG Green VCCINT 0.85VDC power on
DS21 VCCPSINTFP_PG Green VCCPSINTFP 0.85VDC power on
DS22 VCC1V8 Green VCC1V8 1.8VDC power on
DS23 VCC1V2_PG Green VCC1V2 1.2VDC power on
