Appendix D: HW-FMC-XM500
AMS RFMC Plug-in Card Interface
On the bottom of the XM500 card, two Samtec LPAM (8x40) terminals provide access to the
ADC/DAC clocking and data path signals. The Samtec part number is
LPAM-40-010-S-08-2-K-TR. Figure D-1 shows the Samtec LPAM connector.
X-Ref Target - Figure D-1
Figure D-1: Samtec LPAM Connector
NO OF
ROWS
B
-04
(8.18)
.322
-06
(10.72)
.422
-08
(13.26)
.522
LEAD STYLE A
-01.0
(3.68)
.145
-01.5
(4.19)
.165
B
(1,27) .050
No. of positions x
(1,27) .050 + (6,76) .266
(1,27)
.050
(1,27)
.050
(1,32) .052 DIA
No. of positions x
(1,27) .050 + (3,10) .122
A
X21080-062118
