ZCU111 Board User Guide 26
UG1271 (v1.1) August 6, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
PSMIO
Tab l e 3- 2 provides PS MIO peripheral mapping implemented on the ZCU111 board. See the
Zynq UltraScale+ Device Technical Reference Manual (UG1085) [Ref 3] for more information
on PS MIO peripheral mapping.
Table 3-2: MIO Peripheral Mapping
MIO[0:25] Bank 500 MIO[26:51] Bank 501 MIO[52:77] Bank 502
0 QSPI 26 PMU IN 52 USB0
1QSPI27DPAUX53USB0
2 QSPI 28 DPAUX 54 USB0
3QSPI29DPAUX55USB0
4 QSPI 30 DPAUX 56 USB0
5 QSPI 31 Not assigned/no connect 57 USB0
6 Not assigned/no connect 32 PMU OUT 58 USB0
7 QSPI 33 PMU OUT 59 USB0
8 QSPI 34 PMU OUT 60 USB0
9 QSPI 35 PMU OUT 61 USB0
10 QSPI 36 PMU OUT 62 USB0
11 QSPI 37 PMU OUT 63 USB0
12 QSPI 38 GPIO 64 GEM3
13 GPIO 39 SD1 65 GEM3
14 I2C0 40 SD1 66 GEM3
15 I2C0 41 SD1 67 GEM3
16 I2C1 42 SD1 68 GEM3
17 I2C1 43 Not assigned/no connect 69 GEM3
18 UART0 44 Not assigned/no connect 70 GEM3
19 UART0 45 SD1 71 GEM3
20 Not assigned/no connect 46 SD1 72 GEM3
21 Not assigned/no connect 46 SD1 73 GEM3
22 GPIO 48 SD1 74 GEM3
23 GPIO 49 SD1 75 GEM3
24 Not assigned/no connect 50 SD1 76 MDI03
25 Not assigned/no connect 51 SD1 77 MDI03
