Xinje DS5E Series Manual

P0- Function Unit Default value Range Effective Suitable mode
thermocouple
1 - wire break alarm of shielded
thermocouple
74 Blocking alarm time ms
Set as the
model
0~65535 √ 1|3|5|6|7|8|9|10
75 Blocking alarm speed rpm 50 5~9999 √ 1|3|5|6|7|8|9|10
79
Absolute value encoder battery
undervoltage alarm switch
0 - used as absolute encoder
1 - used as an incremental encoder
2 - used as absolute encoder, ignoring
multiturn overflow alarm
- 1 0~2 ● 1|3|5|6|7|8|9|10
80
Thermal Power Protection of Motor
0-current protection
1-Average Thermal Power Protection
2-Analog Thermal Power Protection
- 2 0~2 ● 1|3|5|6|7|8|9|10
92
～
93
32-bit electronic gear ratio numerator.
take effect when P0-11
～
P0-14 is 0. P0-
92*1 + P0-93 *10000
- 1
1~9999
○ 5|6
1~65535
94
～
95
32-bit electronic gear ratio denominator.
take effect when P0-11
～
P0-14 is 0. P0-
94*1 + P0-95 *10000
- 1
1~9999
○ 5|6
1~65535
P1-XX：
P1- Function Unit Default value Range Effective Suitable mode
00 First speed loop gain 0.1Hz
According to
the model
10~20000 √ 3|5|6|7|8|9|10
01
Integral Time Constant of the
First Speed Loop
0.01ms
According to
the model
15~51200 √ 3|5|6|7|8|9|10
02 First position loop gain 0.1/s
According to
the model
10~20000 √ 3|5|6|7|8|9|10
