Xinje DS5E Series Manual

P7- Function Unit
Default
value
Range Effective Suitable mode
2
：
1 bit
11.3
RS232 parity bit
0-no parity
1-odd parity
2-even parity
Parity bit 2 0~2 √ 1|2|3|4|5|6|7|10
20 Return to zero direction (bus) - 1 -9999~99999 √ 10
21
Filtering time after return to
zero(bus)
ScanA Cycle 400 1~65535 √ 10
P8-XX：
P8- Function Unit Default value Range Effective Suitable mode
25
Direct display content setting
when the panel is powered on
- 0 0~2 ▲ 1|2|3|4|5|6|7|8|9|10
P9-XX：
P9- Function Unit
Default
value
Range Effective Suitable mode
11.0
Number of Z phases found when
back to the origin
- 0
0~f
○ 5|6
11.1
Trigger mode of new return to
origin
0 - it is forbidden to trigger back
to the original point
1 - trigger return to origin through
SI terminal
0-2 - return to the original point
immediately after enabling
- 0 0~2 ○ 5|6
11.2 0 - new homing mode 0
1 - return to origin mode 1
- 0 0~7 ○ 5|6
110
