Xinje DS5E Series Manual

P3- Function Unit
Default
value
Range Effective Suitable mode
28 Internal forward torque limit % 300 0~1000 √ 1|2|3|4|5|6|7|10
29 Internal reverse torque limit % 300 0~1000 √ 1|2|3|4|5|6|7|10
30 external forward torque limit % 300 0~1000 √ 1|2|3|4|5|6|7|10
31 external reverse torque limit % 300 0~1000 √ 1|2|3|4|5|6|7|10
32 Brake torque 1% 100 0~1000 √ 1|2|3|4|5|6|7|10
33 Preset torque % 0 -1000~1000 √ 1
38
Anti-blocking forward torque
limit
% 300 0~1000
√
1|2|3|4|5|6|7|8|9|10
39
Anti-blocking reverse torque
limit
% 300 0~1000
√
1|2|3|4|5|6|7|8|9|10
45 Torque mode switching delay ms 40 0~9999 √ 1|2
P4-XX：
P4- Function Unit
Default
value
Range
Effect
ive
Suitable
mode
00.0
Z phase signal numbers
The Z phase signal numbers after leaving the limit
switch (note: stop when N+1 Z phase signal reached)
piece 2 0~f ○ 5|6|10
00.1
Search the origin function
0-OFF
1-ON
- 0 0~1 ○ 5|6|10
00.2
return to zero overrun prohibition
0-not prohibit
1-prohibit
- 0 0~1 ○ 5|6|10
01 Speed of hitting the proximity switch rpm 600 0~65535 ○ 5|6|10
02 Speed of leaving proximity switch rpm 100 0~65535 ○ 5|6|10
03.0
Internal Location Given Mode Sets Location Mode
0-relative positioning
1-Absolute positioning
- 0 0~1 ○ 5
100
