Rpm 30 0~10000 All the modes Servo bb At once
P5-09 Brake command waiting time
Unit Default
setting
Setting range Suitable mode Modify effective
1ms 500 0~65535 All the modes Servo bb At once
When the servo motor with brake is off due to the disappearance of input signal "/ S-ON" during motor
rotation or the occurrence of alarm, the braking time can be set.
Since the brake of the servo motor is designed as position holding, it must be activated at the appropriate time
when the motor stops. While observing the action of the machine, adjust the user parameters.
The conditions under which the / BK signal changes from on to off during motor rotation are as follows (any of
the two conditions takes effect):
(1) When the speed of the motor is below the set value of P5-08 after the servo is off;
(2) When the set time of P5-09 is exceeded after the servo is off.
44
