Xinje DS5K Series User Manual

position loop gain P1-02: 200
position loop gain P1-02: 700
position loop gain P1-02: 700
Model loop gain P2-49: 300
Model loop gain P2-49: 300
Model loop gain P2-49: 4000
Phenomenon: Running jitter,
slow response
Phenomenon: smooth operation
and slow response
Phenomenon: smooth operation
and fast response
Note: The above curves only show the effect of the parameters, not the real running curves.
6.1.4 Torque disturbance observation
Disturbance observer can reduce the influence of external disturbance on servo system and improve the
anti-disturbance ability by detecting and estimating the external disturbance torque of the system and
compensating the torque command.
If the soft mode is selected in the auto-tuning mode, the disturbance observer will be closed
automatically, and the gain of the disturbance observer will not change. If the fast positioning or fast
positioning (control overshoot) is selected, the disturbance observer will be opened automatically, and
the gain of the disturbance observer will be modified to 85. The relevant parameters of this function no
need to be set manually by users.
Parameter
Meaning
Default
setting
Modification
Effective
P2-00
n.□□□0
Turn-off of disturbance observer
n.□□□0
Servo bb
At once
n.□□□1
Turn-on of disturbance observer
Parameter
Meaning
Default
setting
Unit
Setting
range
Modify
Effective
P2-41
Disturbance
observer gain
85
%
0~100
Anytime
At once
6.2 Rotary inertia presumption
6.2.1 Overview
Rotational inertia estimation is the function of automatic operation (forward and reverse) in the driver
and estimate the load inertia in operation.
Rotational inertia ratio (the ratio of load inertia to motor rotor inertia) is a benchmark parameter for
gain adjustment, and it must be set to the correct value as far as possible.
Parameter
Meaning
Default
setting
Unit
Setting range
Modification
Effective
P0-07
First inertia ratio
200
%
0~50000
Anytime
At once
6.2.2 Notes
Occasions where inertia cannot be presumed
➢ Mechanical systems can only operate in one direction
The occasion where inertia presumption is easy to fail
➢ Excessive load moment of inertia
➢ The running range is narrow and the travel is less than 0.5 circles.
➢ The moment of inertia varies greatly during operation.
➢ Mechanical rigidity is low and vibration occurs when inertia is presumed.
Notes of Inertia Presumption
