Xinje DS5K Series User Manual

►► Confirmation on product arrival
After the product arrives, please confirm the integrity of the product in the following aspects.
Items
Notes
Does the product on arrival match the
specified model?
Please confirm according to the nameplate of servo motor
and servo unit.
Does the servomotor shaft rotate
smoothly?
The servo motor shaft is normal if it can be turned
smoothly by hand. Servo motors with brakes, however,
cannot be turned manually.
Is there any damage?
Check the overall appearance, and check for damage or
scratches that may have occurred during shipping.
Are there any loose screws?
Check screws for looseness using a screwdrive.
Is the motor code the same with the
code in drive?
Check the motor code marked on the nameplates of the
servomotor and the parameter U3-00 on the servo drive.
If any of the above is faulty or incorrect, contact Xinje or an authorized distributor.
tudonghoatoancau.com

Xinje DS5K Series Specifications

General

Category	Servo Drives
Model	DS5K Series
Control Mode	Position control, Speed control, Torque control
Communication Interface	CANopen
Position Control Mode	CW/CCW
Feedback	Incremental Encoder, Absolute Encoder
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C to +70°C
Vibration Resistance	5.9 m/s² (10-55Hz)
Installation Altitude	Below 1000m
Input Voltage	Single/Three-phase 220VAC or Three-phase 380VAC (depending on the specific model)
Humidity	Less than 90%RH (non-condensing)
