Page 128 FTDX5000 OPERATING MANUAL
MODE-PKT GROUP
083 PKT LCUT FRQ
Function: Selects the cutoff frequency of the lower side
of the RX audio filter in the Packet mode.
Available Values: OFF / 100Hz ~ 1000Hz (50 Hz/step)
Default Setting: 300Hz
084 PKT LCUT SLP
Function: Selects the filter slope of the lower side of the
RX audio filter in the Packet mode.
Available Values: 6dB/oct or 18dB/oct
Default Setting: 18dB/oct
085 PKT HCUT FRQ
Function: Selects the cutoff frequency of the upper side
of the RX audio filter in the Packet mode.
Available Values: OFF / 700Hz ~ 4000Hz (50 Hz/step)
Default Setting: 3000Hz
086 PKT HCUT SLP
Function: Selects the filter slope of the upper side of the
RX audio filter in the Packet mode.
Available Values: 6dB/oct or 18dB/oct
Default Setting: 18dB/oct
087 PKT PKTDISP
Function: Sets the packet frequency display offset.
Available: –3000Hz ~ 3000Hz (10 Hz/step)
Default: 0Hz
088 DATA PKT SFT
Function: Sets the carrier point during the SSB packet
operation.
Available: –3000Hz ~ 3000Hz (10 Hz/step)
Default: 1000Hz (typical center frequency for PSK31, etc.)
MENU MODE
MODE-FM GROUP
075 F3E LCUT FRQ
Function: Selects the cutoff frequency of the lower side
of the RX audio filter in the FM mode.
Available Values: OFF / 100Hz ~ 1000Hz (50 Hz/step)
Default Setting: OFF
076 F3E LCUT SLP
Function: Selects the filter slope of the lower side of the
RX audio filter in the FM mode.
Available Values: 6dB/oct or 18dB/oct
Default Setting: 6dB/oct
077 F3E HCUT FRQ
Function: Selects the cutoff frequency of the upper side
of the RX audio filter in the FM mode.
Available Values: OFF / 700Hz ~ 4000Hz (50 Hz/step)
Default Setting: OFF
078 F3E HCUT SLP
Function: Selects the filter slope of the upper side of the
RX audio filter in the FM mode.
Available Values: 6dB/oct or 18dB/oct
Default Setting: 6dB/oct
079 F3E MIC GAIN
Function: Sets the microphone gain for the FM mode.
Available Values: MCVR / 0 ~ 100
Default Setting: 50
When this menu is set to “MCVR”, you may adjust the
microphone gain using the front panel
[
MIC
]
knob.
080 F3E MIC SEL
Function: Selects the microphone to be used on the FM
mode.
Available Values: FRONT / DATA / PC
Default Setting: FRONT
FRONT: Selects the microphone connected to the front
panel MIC jack while using the FM mode.
DATA: Selects the microphone connected to pin 1 of
the PACKET Jack while using the FM mode.
PC: This parameter is for future expansion of this
transceiver’s capabilities, but at this time is
not supported.
081 F3E 28 RPT
Function: Sets the magnitude of the repeater shift on the
28 MHz band.
Available Values: 0kHz ~ 1000kHz (10 kHz/step)
Default Setting: 100kHz
082 F3E 50 RPT
Function: Sets the magnitude of the repeater shift on the
50 MHz band.
Available Values: 0kHz ~ 4000kHz (10 kHz/step)
Default Setting: 1000kHz
