Page 135FTDX5000 OPERATING MANUAL
TX AUDIO GROUP
157 TAUD EQ3 FRQ
Function: Selects the center frequency of the high range
for the parametric microphone equalizer.
Available Values: OFF / 1500Hz ~ 3200Hz (100 Hz/step)
Default Setting: OFF
OFF: The equalizer gain and Q-factor
are set to factory defaults (flat).
1500Hz ~ 3200Hz: Center frequencies of 1500 Hz ~
3200 Hz. You may adjust the
equalizer gain and Q-factor in this
selected audio frequency via menu
items “158 TAUD EQ3 LVL” and
“159 TAUD EQ3 BW”.
158 TAUD EQ3 LVL
Function: Adjusts the equalizer gain of the high range of
the parametric microphone equalizer.
Available Values: –20 ~ 10
Default Setting: 5
159 TAUD EQ3 BW
Function: Adjusts the Q-factor of the high range of the
parametric microphone equalizer.
Available Values: 1 ~ 10
Default Setting: 10
160 TAUD PE1 FRQ
Function: Selects the center frequency of the lower range
for the parametric microphone equalizer when the speech
processor is activated.
Available Values: OFF / 100Hz ~ 700Hz (100 Hz/step)
Default Setting: 200Hz
OFF: The equalizer gain and Q-factor are
set to factory defaults (flat).
100Hz ~ 700Hz: Center frequencies of 100 Hz ~ 700
Hz. You may adjust the equalizer
gain and Q-factor at this selected
audio frequency via menu items “161
TAUD PE1 LVL” and “162 TAUD
PE1 BW”.
161 TAUD PE1 LVL
Function: Adjusts the equalizer gain of the low range of
the parametric microphone equalizer when the speech pro-
cessor is activated.
Available Values: –20 ~ 10
Default Setting: 0
162 TAUD PE1 BW
Function: Adjusts the Q-factor of the low range of the
parametric microphone equalizer when the speech proces-
sor is activated.
Available Values: 1 ~ 10
Default Setting: 2
163 TAUD PE2 FRQ
Function: Selects the center frequency of the middle range
for the parametric microphone equalizer when the speech
processor is activated.
Available Values: OFF / 700Hz ~ 1500Hz (100 Hz/step)
Default Setting: 800Hz
OFF: The equalizer gain and Q-factor are
set to factory defaults (flat).
700Hz ~ 1500Hz: Center frequencies of 700 Hz ~
1500 Hz. You may adjust the equal-
izer gain and Q-factor at this se-
lected audio frequency via menu
items “164 TAUD PE2 LVL” and
“165 TAUD PE2 BW”.
164 TAUD PE2 LVL
Function: Adjusts the equalizer gain of the middle range
of the parametric microphone equalizer when the speech
processor is activated.
Available Values: –20 ~ 10
Default Setting: 0
165 TAUD PE2 BW
Function: Adjusts the Q-factor of the middle range of the
parametric microphone equalizer when the speech proces-
sor is activated.
Available Values: 1 ~ 10
Default Setting: 1
166 TAUD PE3 FRQ
Function: Selects the center frequency of the high range
for the parametric microphone equalizer when the speech
processor is activated.
Available Values: OFF / 1500Hz ~ 3200Hz (100 Hz/step)
Default Setting: 2100Hz
OFF: The equalizer gain and Q-factor
are set to factory defaults (flat).
1500Hz ~ 3200Hz: Center frequencies of 1500 Hz ~
3200 Hz. You may adjust the
equalizer gain and Q-factor in this
selected audio frequency via menu
items “167 TAUD PE3 LVL” and
“168 TAUD PE3 BW”.
167 TAUD PE3 LVL
Function: Adjusts the equalizer gain of the high range of
the parametric microphone equalizer when the speech pro-
cessor is activated.
Available Values: –20 ~ 10
Default Setting: 0
168 TAUD PE3 BW
Function: Adjusts the Q-factor of the high range of the
parametric microphone equalizer when the speech proces-
sor is activated.
Available Values: 1 ~ 10
Default Setting: 1
MENU MODE
