115
MIDI Functions
MIDI Note Numbers
1
Select the Note Number display page by pressing the [PAGE+] or [PAGE–]
button. The current note number flashes next to the “NT” prompt.
2
Press the drum pad you want to modify.
3
Change the MIDI note number of the current pad by rotating the Jog Dial
or by using the [ +1 ] and [ –1 ] buttons.
For the drum pads from “000” to “059” (the drum voices) you can assign
an individual MIDI note number in the range of “000” to “127” or “OFF”.
For the drum pads from “060” to “119” (the bass voices) you can assign a
MIDI note number in the range of “000” to “127”. However, all the note
numbers will be affected by the change. (The note number range depends
on which pad you select.)
NOTE
You can use Pad Bank Mode to select another group of drum pads. See page 84 for
instructions regarding Pad Bank Mode.
An alternative method is to press the
[ > ] cursor button to change the focus to the
pad prompt (the “
PAD” indicator starts flashing). Select a pad with the Jog Dial or
by using the
[ +1 ] and [ –1 ] buttons, then press the [ < ] cursor button to change the
focus back to the note assignment.
NOTE
If you are modifying the drum voices and did not select one of the user tables with
the previous display page, you will see the error message “
PRESET” when you
attempt to modify the table. The preset table contains the mapping for General
MIDI drum voices and cannot be changed. However, if you are modifying the bass
voice, you can change the value of the preset table.
PAGE – PAGE +
PATTERN MIDI
A CHASE
PAD
MAIN A
PAD BANK
OTHERS
HH
SD
BD
To Next Page
