128
■ Specifications
Tone
Generator
Type AWM (Advanced Wave Memory)
Polyphony 28-note
Voices 300
Digital Signal
Processor
Type 6 Reverbs, 4 Delays
Parameters On/Bypass; Send Level, Return Level, Reverb Time, Feedback Gain, Delay
Time
Sequencer Patterns Patterns 50 Presets, 50 Users, 50 Combinations
Sections Intro, Main A, Main B, Fill AB, Fill BA, Ending
Tracks Bass Drum, Snare Drum, Hi-hat, Others
Tempo 40 - 250
Note
Resolution
96 Clocks per Quarter Note
Pattern Play Initial Tempo, Swing, Groove (14 types), Velocity Modify,
Clear, Copy, Name
Pattern Record Quantize, Time Signature, Measure, Click, Delete;
Record Data (Level, Pad, Gate Time)
Songs Songs 50, Demo
Song Play Initial Tempo, Repeat, Chain, Clear, Copy, Name
Song Record Part, Part Delete, Part Insert, Click; Record Data
(Pattern, Section, Fill In Start Position)
Drum Kit Drum Kits 20 Presets, 20 Users
Parameters Assign, Level, Pan, Pitch, Decay, Sensitivities (Level, Pitch, Decay,
Balance), Voice Polyphony, Alternate Group, Trigger/Note Driven, Pad
Sensitivity, Chase, Copy, Name
Pad Banks 5 Drum Pad Banks (60 Pads), 1 Bass Pad Bank (60 Pads=5 Octaves)
Drum Pads 12 velocity Sensitive Pads
MIDI Parameters Sync., Drum/Bass Channels, Program Change, Note Number (4 Note
Tables), Drum/Bass Volumes, Drum/Bass Expressions, Bulk Send
Controls Power, Volume, Jog/Shuttle Dials, Mode Keys, Page+/Page-, Enter, +1/-1, d//c Cursors,
Record, Stop, Play, Top, Backward, Forward, Track Select/Mute, Section
Indicators Multi-function LCD (66 × 42mm), Play LED, Record LED
Connectors Headphones, Output (L/Mono and R), MIDI In/Out, DC In
Included
Accessory
PA-3 AC Adaptor (except in the UK)
Electrical
Characteristics
Power Consumption 3.5 W
Output Impedance - Line: 1kΩ; Headphones: 47Ω
Dimensions
(W × D × H)
240 × 176 × 48 mm (9 1/2” × 6 7/8” × 1 7/8”)
Weight 700g (1lbs 9oz)
