Yealink CP860 Administrator's Guide

Administrator’s Guide for CP860 IP conference phones
112
2. Enter the desired time (in seconds) in the Auto-Answer Delay (1~4s) field.
3. Click Confirm to accept the change.
To configure auto answer and auto answer mute via phone user interface:
1. Press Menu->Features->Auto Answer.
2. Press the or soft key to select Enable from the Auto Answer field.
3. Press the or soft key to select Enable from the Auto Answer Mute field.
4. Press the Save soft key to accept the change.
Anonymous call allows the caller to conceal the identity information displayed on the
callee’s screen. The callee’s phone LCD screen prompts an incoming call from
anonymity.
Example of anonymous SIP header:
Via: SIP/2.0/UDP 10.2.8.183:5063;branch=z9hG4bK1535948896
From: "Anonymous" <sip:anonymous@anonymous.invalid>;tag=128043702
To: <sip:1011@10.2.1.199>
Call-ID: 1773251036@10.2.8.183
CSeq: 1 INVITE
Contact: <sip:1012@10.2.8.183:5063>
Content-Type: application/sdp
Allow: INVITE, INFO, PRACK, ACK, BYE, CANCEL, OPTIONS, NOTIFY, REGISTER, SUBSCRIBE, REFER,
PUBLISH, UPDATE, MESSAGE

Yealink CP860 Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.729ab, iLBC
Handset type	-
Product type	IP Phone
Product color	Black
Display resolution	192 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Networking standards	IEEE 802.1x, IEEE 802.3af
Supported network protocols	IPv4/IPv6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Number of handles included	- pc(s)
Storage temperature (T-T)	10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	260 mm
Width	320 mm
Height	52 mm
