Yealink CP860 Administrator's Guide

Administrator’s Guide for CP860 IP conference phones
32
Parameters
Permitted Values
Default
Network->Advanced->Port Link->WAN Port Link
Phone User Interface:
None
To configure the transmission method of Ethernet port via web user interface:
1. Click on Network->Advanced.
2. Select the desired value from the pull-down list of WAN Port Link.
3. Click Confirm to accept the change.
This section provides information on upgrading the IP phone firmware. Two methods of
firmware upgrade:
 Manually, from the local system
 Automatically, from the provisioning server
The associated firmware name of the CP860 IP conference phone is 37.x.0.x.rom (x is
replaced by the actual firmware version).
Note
You can download the latest firmware online:
http://www.yealink.com/DocumentDownload.aspx?CateId=142&flag=142.
Do not unplug the network and power cables when the IP phone is upgrading firmware.

Yealink CP860 Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.729ab, iLBC
Handset type	-
Product type	IP Phone
Product color	Black
Display resolution	192 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Networking standards	IEEE 802.1x, IEEE 802.3af
Supported network protocols	IPv4/IPv6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Number of handles included	- pc(s)
Storage temperature (T-T)	10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	260 mm
Width	320 mm
Height	52 mm
