Yealink CP860 Administrator's Guide

Administrator’s Guide for CP860 IP conference phones
162
2. In the desired programable key field, select Call Return from the pull-down list of
Type.
3. Click Confirm to accept the change.
Calling line identification presentation (CLIP) allows IP phones to display the caller
identity, derived from a SIP header contained in the INVITE message when receiving an
incoming call. IP phones support deriving caller identity from three types of SIP header:
From, P-Asserted-Identity and Remote-Party-ID. Identity presentation is based on the
identity in the relevant SIP header.
If the caller has existed in the local directory, the local name assigned to the caller
should be preferentially displayed and stored in the call log.
For more information on calling line identification presentation, refer to Calling and
Connected Line Identification Presentation on Yealink IP Phones , available online:
http://www.yealink.com/DocumentDownload.aspx?CateId=142&flag=142.
Procedure
CLIP can be configured using the configuration files or locally.
Configuration File
<MAC>.cfg
Configure the presentation of
the caller identity.
Parameter:
account.X.cid_source
Local
Web User Interface
Configure the presentation of
the caller identity.
Navigate to:
http://<phoneIPAddress>/servl
et?p=account-adv&q=load&ac
c=0

Yealink CP860 Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.729ab, iLBC
Handset type	-
Product type	IP Phone
Product color	Black
Display resolution	192 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Networking standards	IEEE 802.1x, IEEE 802.3af
Supported network protocols	IPv4/IPv6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Number of handles included	- pc(s)
Storage temperature (T-T)	10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	260 mm
Width	320 mm
Height	52 mm
