Yealink CP860 Administrator's Guide

Administrator’s Guide for CP860 IP conference phones
82
"([1-9])([2-7])3" would match “923”, “153”, “673”, etc.
$
The “$” followed by the sequence number of a parenthesis means
the characters placed in the parenthesis. The sequence number
stands for the corresponding parenthesis. Example:
A replace rule configuration, Prefix: "001(xxx)45(xx)", Replace:
"9001$145$2". When you dial out "0012354599" on your phone, the IP
phone will replace the number with "90012354599". “$1” means three
digits in the first parenthesis, that is, “235”. “$2” means two digits in
the second parenthesis, that is, “99”.
Replace rule is an alternative string that replaces the numbers entered by the user. IP
phones support up to 100 replace rules, which can be created either one by one or in
batch using a replace rule template. For more information on the replace rule template,
refer to Replace Rule Template on page 324.
Procedure
Replace rule can be created using the configuration files or locally.
Configuration File
y000000000037.cfg
Create the replace rule for the IP
phone.
Parameters:
dialplan.replace.prefix.X
dialplan.replace.replace.X
Configure the access URL of the
replace rule template.
Parameter:
dialplan_replace_rule.url
Local
Web User Interface
Create the replace rule for the IP
phone.
Navigate to:
http://<phoneIPAddress>/servlet
?p=settings-dialplan&q=load
Details of Configuration Parameters:
Parameters
Permitted Values
Default
dialplan.replace.prefix.X
(X ranges from 1 to 100)
String within 32 characters
Blank

Yealink CP860 Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.729ab, iLBC
Handset type	-
Product type	IP Phone
Product color	Black
Display resolution	192 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Networking standards	IEEE 802.1x, IEEE 802.3af
Supported network protocols	IPv4/IPv6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Number of handles included	- pc(s)
Storage temperature (T-T)	10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	260 mm
Width	320 mm
Height	52 mm
