Yealink CP860 Administrator's Guide

Configuring Basic Features
165
Parameter
Permitted Values
Default
From header.
Web User Interface:
None
Phone User Interface:
None
DTMF (Dual Tone Multi-frequency), better known as touch-tone, is used for
telecommunication signaling over analog telephone lines in the voice-frequency band.
DTMF is the signal sent from the IP phone to the network, which is generated when
pressing the IP phone’s keypad during a call. Each key pressed on the IP phone
generates one sinusoidal tone of two frequencies. One is generated from a high
frequency group and the other from a low frequency group.
The DTMF keypad is laid out in a 4× 4 matrix, with each row representing a low
frequency, and each column representing a high frequency. Pressing a digit key (such
as '1') will generate a sinusoidal tone for each of two frequencies (697 and 1209 hertz
(Hz)).
DTMF Keypad Frequencies:
1209 Hz
1336 Hz
1447 Hz
1633 Hz
697 Hz
1
2
3
A
770 Hz
4
5
6
B
852 Hz
7
8
9
C
941 Hz
*
0
#
D
Three methods of transmitting DTMF digits on SIP calls:
 RFC 2833 --DTMF digits are transmitted by RTP Events compliant to RFC 2833.
 INBAND -- DTMF digits are transmitted in the voice band.
 SIP INFO -- DTMF digits are transmitted by the SIP INFO messages.
The method of transmitting DTMF digits is configurable on a per-line basis.
RFC 2833
DTMF digits are transmitted using the RTP Event packets that are sent along with the
voice path. These packets use RFC 2833 format and must have a payload type that
matches what the other end is listening to. The payload type for the RTP Event packets is

Yealink CP860 Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.729ab, iLBC
Handset type	-
Product type	IP Phone
Product color	Black
Display resolution	192 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Networking standards	IEEE 802.1x, IEEE 802.3af
Supported network protocols	IPv4/IPv6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Number of handles included	- pc(s)
Storage temperature (T-T)	10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	260 mm
Width	320 mm
Height	52 mm
