Yealink CP860 Administrator's Guide

Administrator’s Guide for CP860 IP conference phones
14
Icon
Description
Call Hold
Call Mute
Ringer volume is 0
Keypad Lock
Alphanumeric input mode
Numeric input mode
Multi-lingual lowercase letters input mode
Multi-lingual uppercase letters input mode
Multi-lingual uppercase and lowercase letters
input mode
Call Forward/Forwarded Calls
Missed Calls
Received Calls
Placed Calls
USB flash drive is inserted
USB flash drive is detecting
High Definition Voice
IP phones can be configured automatically through configuration files stored on a
central provisioning server, manually via the phone user interface or web user interface,
or by a combination of the automatic and manual methods.
The recommended method for configuring IP phones is automatically through a central
provisioning server. If a central provisioning server is not available, the manual method
will allow changes to most features.
The following sections describe how to configure IP phones using each method.
 Phone User Interface

Yealink CP860 Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.729ab, iLBC
Handset type	-
Product type	IP Phone
Product color	Black
Display resolution	192 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Networking standards	IEEE 802.1x, IEEE 802.3af
Supported network protocols	IPv4/IPv6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Number of handles included	- pc(s)
Storage temperature (T-T)	10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	260 mm
Width	320 mm
Height	52 mm
