Yealink CP860 Administrator's Guide

Administrator’s Guide for CP860 IP conference phones
128
An outbound proxy server can receive all initiating request messages and route them to
the designated destination. If the IP phone is configured to use an outbound proxy
server within a dialog, all SIP request messages from the IP phone will be sent to the
outbound proxy server forcefully.
Note
Procedure
Use outbound proxy in dialog can be configured using the configuration files or locally.
Configuration File
y000000000037.cfg
Specify whether to use outbound
proxy in a dialog.
Parameter:
sip.use_out_bound_in_dialog
Local
Web User Interface
Specify whether to use outbound
proxy in a dialog.
Navigate to:
http://<phoneIPAddress>/servlet
?p=features-general&q=load
Details of the Configuration Parameter:
Parameter
Permitted Values
Default
sip.use_out_bound_in_dialog
0 or 1
1
Description:
Enables or disables the IP phone to keep sending SIP requests to the outbound proxy
server in a dialog.
0-Disabled
1-Enabled
If it is set to 1 (Enabled), all the SIP request messages from the IP phone will be
forced to send to the outbound proxy server in a dialog.
Note: If you change this parameter, the IP phone will reboot to make the change take
effect.
Web User Interface:
Features->General Information->Use Outbound Proxy In Dialog
Phone User Interface:
To use this feature, make sure the outbound server has been correctly configured on the
IP phone.

Yealink CP860 Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.729ab, iLBC
Handset type	-
Product type	IP Phone
Product color	Black
Display resolution	192 x 64 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	1
Networking standards	IEEE 802.1x, IEEE 802.3af
Supported network protocols	IPv4/IPv6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Number of handles included	- pc(s)
Storage temperature (T-T)	10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	260 mm
Width	320 mm
Height	52 mm
