Yealink CP935W User Manual

Yealink CP965 User Guide
Procedure
1.
Select .
The icon changes to , the number will increase if you set more marks.
Stopping a Recording
You can stop recording a call before the call ends. The recording also stops when the active call ends. The record-
ing will be saved as a "*.aac" file in the internal SD card or the USB flash drive automatically.
Procedure
1.
Do one of the following:
l
Select > Stop.
The recording icon and recording duration disappears. The screen prompts a message that the call is recor-
ded successfully.
l
Select .
The recording icon and recording duration disappears, and the phone returns to the idle screen. The screen
prompts a message that the call is recorded successfully.
Checking Storage Space
You can check the total space or available space of the phone or connected USB flash drive.
Procedure
1. Select More > Recorder to launch the Recorder application.
2. If you want to check the storage space of the USB flash drive, select USB.
Multicast Paging
Multicast Paging allows you to broadcast instant audio announcements to users who are listening to a specific mul-
ticast group on a specific channel.
The phone supports the following 31 channels:
l
0: Broadcasts are sent to channel 0. Note that the Yealink IP phones running old firmware version (old paging
mechanism) can be regarded as listening to channel 0. It is the default channel.
40

Yealink CP935W Specifications

General

Control type	Touch
Product type	IP conference phone
Voice codecs	AMR, G.711a, G.722, G.722.1C, G.723, G.726, G.729, G.729A, OPUS, PCMA, iLBC
Product color	Black
Speaker power	5 W
Noise reduction	Yes
Speaker diameter	56 mm
Bluetooth version	4.2
Display resolution	480 x 800 pixels
Phonebook capacity	1000 entries
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	256-bit AES, HTTPS, MD5, SRTP, TLS, WPA2
Microphone pick-up range	6 m
Number of microphone arrays	6
Conference call ways quantity	5
USB version	2.0
USB connector type	USB Type-C
USB ports quantity	1
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Power consumption (max)	6 W
Power consumption (typical)	2.2 W

Weight and Dimensions

Depth	285.2 mm
Width	288.6 mm
Height	63.9 mm

Summary

Call Features

Placing Calls

Provides instructions on how to initiate outgoing calls using various methods.

Answering Calls

Explains how to accept incoming calls manually or automatically.

Holding and Resuming Calls

Covers placing active calls on hold and retrieving them later.

Transferring Calls

Explains different methods for transferring calls to other parties.

Conference Calls

Guides on setting up and managing local and network conference calls.

Call Recording

Details how to record calls and conferences, and manage recordings.

Multicast Paging

Advanced Call Features

Call Pickup

Describes how to answer calls directed to other phones or groups.

Call Park

Explains how to place calls on hold and retrieve them from other phones.

Busy Lamp Field (BLF)

Shared Line

Directory

Local Directory

Explains managing contacts, groups, and blocklists within the phone's directory.

System Applications

Recorder

Covers using the phone's built-in recorder to capture audio and manage recordings.

Customizing Your Phone

Changing the Administrator Password

Instructions for changing the default administrator password for security.

Phone Lock

Explains how to set up and manage phone lock features for security.

Line Keys

Using Your Phone with PC

Connecting the PC to the Phone

Instructions for connecting the phone to a PC via USB for audio functions.

Setting the Phone as PC Audio Device

Using Star Connection Feature

Configuring the Primary Phone

Steps to set up a star connection group and designate a primary phone.

Configuring the Subsidiary Phone

Connecting a Mobile Phone Using Bluetooth

Activating the Bluetooth Mode

Pairing and Connecting the Bluetooth-enabled Mobile Phone

Steps to pair and connect a mobile phone via Bluetooth.

Syncing the Mobile Contacts to the Phone

Handling a Mobile Phone Call on the Phone

Configuring the Phone Audio Feature

Wireless Network

Activating the Wi-Fi Mode

Connecting to the Wireless Network

Steps to connect the phone to available Wi-Fi networks.

Using Your Phone with PSTN Account

Connecting the Expansion PSTN Box CPN10

Configuring the PSTN Account

How to set up and manage PSTN accounts on the phone.

Basic Call Features

Maintaining Your Phone

Diagnosing the Network

Rebooting Your Phone

Steps to restart the phone to resolve minor issues.

Resetting to Factory Settings

How to restore the phone to its original factory default settings.
